Wunderlich Engine Protection ULTIMATE R 12 G/S

Product detailed description

Wunderlich Engine Protection ULTIMATE – comprehensive protection for the engine housing, oil sump and headers of the BMW R 12 G/S

Function and product features

• Black, high-quality engine protection designed in the distinctive Wunderlich Tool Design
• Optimal structural and functional integration
• Provides comprehensive, maximum protection for the engine housing, oil sump, headers and balance pipe
• Tight-fitting shape with minimal exposed surface area, perfectly highlighting the Rallye design and Adventure look
• Maximum ground and lean angle clearance
• The shape of the three-part guard reduces the risk of unpleasant snagging or catching on obstacles in off-road terrain
• Angled deflector plates significantly reduce the risk of stone chips and foreign objects kicked up by the front wheel
• The engine protection reduces thermal stress on the engine by deflecting the surge of spray water thrown up by the front wheel
• Openings support cooling – collected water and spray can freely drain away
• External forces and torque loads are distributed across the four mounting points to effectively reduce stress peaks and absorb vibrations
• Unrestricted accessibility for maintenance work (e.g. oil drain)
• High component rigidity and mechanical stability with significantly reduced weight
• Corrosion-resistant
• Includes all mounting hardware
• With Wunderlich brand logo

Note

• The engine protection can be combined with the DAKAR header guard (#26901-000)

Technical specifications

• Material

• High-strength aluminium, precisely manufactured, featuring integrated vibration-damping mounting elements, recessed fittings and a high-quality powder coating

• Installation
  • At four existing mounting points on the motorcycle
• Dimensions
  • Width: 449 mm
  • Length: 509 mm
  • Material thickness: 3 mm
• Colour
  • Black, finely textured powder coating

Your Wunderlich advantages

• Wunderlich product. Small series. Handcrafted.
• Wunderlich design. Functional and integrated.
• Made in Germany
• Wunderlich 60/5
  • 60-day return policy – try without risk!
  • Plus 5-year warranty.

Rough’n’tough – the functional integral design of the Wunderlich Engine Protection ULTIMATE

This ULTIMATE engine protection is also designed in the authentic Tool Design style. Its functional design and structural integration protect the engine housing, oil sump and headers with balance pipe. The three-part construction fits so closely around the engine unit that not only the frontal exposure is optimised, but also ground and lean angle clearance remain virtually unchanged. The shape of the guard reduces the risk of snagging or hooking on obstacles such as branches, rocks or debris when riding off-road. Openings ensure that water taken in during river crossings can drain freely.

The angled deflector plates divert stones or foreign objects kicked up by the front wheel in such a way that the risk of damage to the headers and engine is significantly reduced. Another advantage of this engine protection: it deflects the surge of spray water downward, helping to considerably reduce thermal stress on the engine housing, headers and seals – especially when the engine is hot.

The complex component shape and geometry are the result of optimising material thickness and weight, while ensuring high structural rigidity and mechanical stability. The outcome is a robust, weight-optimised and form-optimised engine protector that fits closely and organically around the engine, making the “form follows function” design principle clearly evident. The recessed fittings provide no exposed edges and further enhance the Adventure look.

This high-quality engine protection is securely mounted at four existing connection points on the motorcycle. External forces and torque loads are distributed across the mounting points to reduce load and stress peaks. Vibrations are effectively absorbed. As is typical for Wunderlich, unrestricted accessibility for maintenance has been ensured – for example, an opening has been specifically integrated for unimpeded oil drainage. The aluminium engine protector is corrosion-resistant and finished in black. With Wunderlich brand logo.
